Audi A6 C5 facelift (2001-2004) left headlight beam adjusting motor Wiring diagram

This page shows the only wiring diagram for the component.left headlight beam adjusting motor, which is found in the car Audi A6 C5 facelift (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left headlight beam adjusting motor (1 of 1)

Wiring diagram left headlight beam adjusting motor for Audi A6 C5 facelift (2001-2004)

Get access

ANTI-LOCK BRAKES SYSTEM BLU WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMBINATION PROCESSOR FUSE FUSE PANEL (LEFT END OF DASH) GRN WIRE GRN/BLU WIRE HEAD OFF HEADLIGHT ADJUSTMENT CONTROL MODULE (BEHIND GLOVE BOX) HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START IGNITION SWITCH INSTRUMENT CLUSTER LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT HEADLIGHT BEAM ADJUSTING MOTOR LEFT REAR LEVEL CONTROL SYSTEM SENSOR LIGHT SWITCH OFF PARK RIGHT HEADLIGHT BEAM ADJUSTING MOTOR RUN WIRE VIO WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/VIO WIRE

Go to component: -> Headlamps leveling circuit -> LEFT HEADLIGHT BEAM ADJUSTING MOTOR
