Audi A6 C5 facelift (2001-2004) instrument cluster, memory system, anti-theft system Wiring diagram
This page shows the only wiring diagram for the component.instrument cluster, memory system, anti-theft system, which is found in the car Audi A6 C5 facelift (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument cluster, memory system, anti-theft system (1 of 1)
BLK/RED WIRE
BLK/VIO WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL LOCKING CONTROL MODULE (BELOW DRIVER'S SEAT, CARPET)
DIVER'S SIDE DOOR WARNING LIGHT
DRIVER'S SIDE DOOR CONTACT SWITCH
DRIVER'S SIDE DOOR OPENER ILLUMINATION
GRN/YEL WIRE
INSTRUMENT CLUSTER, MEMORY SYSTEM, ANTI-THEFT SYSTEM
LEFT FOOTWELL LIGHT
LEFT FRONT ENTRY LIGHT
LEFT FRONT POWER WINDOW MOTOR
LEFT FRONT POWER WINDOW SWITCH
LEFT REAR DOOR CONTACT SWITCH
LEFT REAR DOOR OPENER ILLUMINATION LEFT REAR ASHTRAY LIGHT
LEFT REAR DOOR WARNING LIGHT
LEFT REAR ENTRY LIGHT
LEFT REAR FOOTWELL LIGHT
LEFT REAR POWER WINDOW MOTOR
PASSENGER MEMORY SEAT CONTROL MODULE
PASSENGER'S DOOR OPENER ILLUMINATION
PASSENGER'S DOOR WARNING LIGHT
PASSENGER'S SIDE DOOR CONTACT SWITCH
POWER SUNROOF CONTROL MODULE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FOOTWELL LIGHT
RIGHT FRONT ENTRY LIGHT
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR ASHTRAY LIGHT
RIGHT REAR DOOR CONTACT SWITCH
RIGHT REAR DOOR OPENER ILLUMINATION
RIGHT REAR DOOR WARNING LIGHT
RIGHT REAR ENTRY LIGHT
RIGHT REAR FOOTWELL LIGHT
RIGHT REAR POWER WINDOW MOTOR
Go to component -> Interior lights circuit (3 of 3) -> INSTRUMENT CLUSTER, MEMORY SYSTEM, ANTI-THEFT SYSTEM
