Audi A6 C5 facelift (2001-2004) defogger switch Wiring diagram
This page shows the only wiring diagram for the component.defogger switch, which is found in the car Audi A6 C5 facelift (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defogger switch (1 of 1)
A/C CONTROL HEAD
ANTI-THEFT SYSTEM (REAR WINDOW GLASS BREAKAGE SENSORS)
BLK WIRE
BLK/YEL WIRE
BRN WIRE
DEFOGGER SWITCH
DRIVER'S SIDE HEATED MIRROR
FUSE
FUSE FUSE PANEL (LEFT END OF DASH)
HOT AT ALL TIMES
HOT IN
LOAD REDUCTION RELAY
MICRO CENTRAL ELECTRIC PANEL (BEHIND LEFT SIDE OF DASH)
PASSENGER'S SIDE HEATED MIRROR
REAR WINDOW DEFOGGER (HEAT ELEMENT)
REAR WINDOW DEFOGGER HEAT ELEMENT/ ANTENNA
RED WIRE
RUN WIRE
SOLID STATE
TELEPHONE/ RADIO ANTENNA AMPLIFIER
W/ WINDOW ANTENNA
W/O WINDOW ANTENNA
WAGON
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Defoggers circuit -> DEFOGGER SWITCH
