Car Wiring Diagrams for Memory systems circuit for Audi A6 C4 (1994-1997)

AUXILIARY RELAY PANEL 1 BACK- REST BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/WHT WIRE CENTRAL LOCKING/ ALARM SYSTEM/ INTERIOR LIGHT DELAY CONTROL MODULE CIRCUIT BREAKER 44 DRIVER SEAT BACKREST ADJUSTING MOTOR DRIVER SEAT FORE/ AFT ADJUSTING MOTOR DRIVER SEAT FRONT HEIGHT ADJUSTING MOTOR DRIVER SEAT REAR HEIGHT ADJUSTING MOTOR DRIVER SEAT SWITCH FORE/ AFT FRONT HEIGHT GRN WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR CONTACT SWITCH MEMORY PROGRAM SWITCH MEMORY SEAT CONTROL MODULE POWER SEAT POWER SUPPLY RELAY REAR HEIGHT RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/WHT WIRE

BACK-UP LIGHTS BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE DE- FOG DRIVER SIDE MIRROR FOLD- AWAY FUSE 15 FUSE 8 FUSE PANEL GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN ACC MEMORY MIRROR CONTROL MODULE MIRROR ADJUSTMENT SWITCH MIRROR FOLD-AWAY CONTROL MODULE MIRROR POSITION MIRROR SELECT PASSENGER SIDE MIRROR POSITION REAR WINDOW DEFOGGER SWITCH RED WIRE RED/BLU WIRE WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE
