Audi A6 C4 (1994-1997) windshield wiper/washer switch, windshield wiper motor, emergency flasher switch Wiring diagram

This page shows the only wiring diagram for the component.windshield wiper/washer switch, windshield wiper motor, emergency flasher switch, which is found in the car Audi A6 C4 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram windshield wiper/washer switch, windshield wiper motor, emergency flasher switch (1 of 1)

Wiring diagram windshield wiper/washer switch, windshield wiper motor, emergency flasher switch for Audi A6 C4 (1994-1997)

Get access

A/C CONTROL HEAD ABS HYDRAULIC UNIT, ABS CONTROL MODULE BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE CENTRAL ELECTRIC PANEL CENTRAL LOCKING/ ALARM SYSTEM/ INTERIOR LIGHT DELAY CONTROL MODULE CIRCUIT BREAKER 43 CIRCUIT BREAKER 44 CIRCUIT BREAKER 80 CIRCUIT BREAKER 83 DATA LINK CONNECTOR DUAL HORN RELAY FOG LIGHT RELAY FROM FUEL PUMP RELAY (DIAGRAM 1 OF 2) FROM IGNITION SWITCH (DIAGRAM 1 OF 2) FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 18 FUSE 19 FUSE 42 FUSE 79 FUSE 92 FUSE PANEL FUSE/ RELAY PANEL GRN WIRE GRY WIRE LIGHT SWITCH LOAD REDUCTION RELAY PASSENGER SEAT ADJUSTING SWITCH POWER SEAT POWER SUPPLY RELAY, SEAT ADJUSTING SWITCHES POWER SUNROOF LOCK RELAY POWER WINDOW CONTROL MODULE RADIO, SPEAKER POWER SUPPLY RELAY REAR WINDOW DEFOGGER SWITCH REAR WINDOW WIPER/WASHER RELAY, REAR WINDOW WASHER PUMP RED WIRE SEAT HEAT REGULATING SWITCHES THIRD SPEED COOLANT FAN CONTROL RELAY, COOLANT FAN CONTROL RELAY TURN SIGNAL SWITCH WASHER/ WIPER INTERMITTENT RELAY WHT WIRE WINDSHIELD WIPER/WASHER SWITCH, WINDSHIELD WIPER MOTOR, EMERGENCY FLASHER SWITCH YEL WIRE

Go to component: -> Power distribution circuit (2 of 2) -> WINDSHIELD WIPER/WASHER SWITCH, WINDSHIELD WIPER MOTOR, EMERGENCY FLASHER SWITCH
