Audi A6 C4 (1994-1997) second speed coolant fan control relay Wiring diagrams

This page contains all the electrical diagrams for the component. second speed coolant fan control relay, in which he is found in the car Audi A6 C4 (1994-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram second speed coolant fan control relay (1 of 3)

Wiring diagram second speed coolant fan control relay for Audi A6 C4 (1994-1997)

Get access

1995 VFTC A/C COMPRESSOR A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C REFRIGERANT HIGH PRESSURE SWITCH A/C REFRIGERANT LOW PRESSURE SWITCH AMBIENT TEMPERATURE SENSOR BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/RED WIRE BLOWER MOTOR BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE COOLANT FAN CONTROL RELAY COOLANT FAN CONTROL THERMO SWITCH COOLANT FAN RESISTOR COOLANT FANS DIGITAL OUTSIDE AIR TEMPERATURE DISPLAY ELECTRONIC THERMO SWITCH ENGINE CONTROL UNIT FRESH AIR BLOWER CONTROL MODULE FRESH AIR INTAKE DUCT TEMPERATURE FRESH AIR RECIRCULATING FLAP VALVE FRESH AIR TEMPERATURE GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE INSTRUMENT CLUSTER LOW COOLANT SWITCH PROTECTION DIODE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE SECOND SPEED COOLANT FAN CONTROL RELAY SENSOR SPEED SENSOR TEMPERATURE SENSOR, HEADLINER TRANSMISSION CONTROL MODULE (A/T) WHT/BLU WIRE WHT/GRN WIRE YEL WIRE

Go to component: -> Automatic a/c-heater system wiring diagram (1995 (early production) circuit 2 of 2) -> SECOND SPEED COOLANT FAN CONTROL RELAY

Wiring diagram second speed coolant fan control relay (2 of 3)

Wiring diagram second speed coolant fan control relay for Audi A6 C4 (1994-1997)

Get access

1995 VFTC A/C COMPRESSOR A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C REFRIGERANT HIGH PRESSURE SWITCH A/C REFRIGERANT LOW PRESSURE SWITCH AMBIENT TEMPERATURE SENSOR BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/RED WIRE BLOWER MOTOR BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE COOLANT FAN CONTROL RELAY COOLANT FAN CONTROL THERMO SWITCH COOLANT FANS DIGITAL OUTSIDE AIR TEMPERATURE DISPLAY ELECTRONIC THERMO SWITCH ENGINE CONTROL UNIT FRESH AIR BLOWER CONTROL MODULE FRESH AIR INTAKE DUCT TEMPERATURE FRESH AIR RECIRCULATING FLAP VALVE FRESH AIR TEMPERATURE GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE INSTRUMENT CLUSTER INTERIOR MONITORING SENSOR CONTROL MODULE LOW COOLANT SWITCH COOLANT FAN RESISTOR PROTECTION DIODE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE SECOND SPEED COOLANT FAN CONTROL RELAY SENSOR SPEED SENSOR SPEEDOMETER TEMPERATURE SENSOR, HEADLINER TRANSMISSION CONTROL MODULE (A/T) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE

Go to component: -> Automatic a/c-heater system wiring diagram (1995 (late production) & 1996 circuit 2 o -> SECOND SPEED COOLANT FAN CONTROL RELAY

Wiring diagram second speed coolant fan control relay (3 of 3)

Wiring diagram second speed coolant fan control relay for Audi A6 C4 (1994-1997)

Get access

A/C CONTROL UNIT A/C REFRIGERANT HIGH PRESSURE AUXILIARY RELAY PANEL 2 BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COOLANT FAN CONTROL RELAY COOLANT FAN CONTROL THERMO SWITCH COOLANT FAN RESISTOR COOLANT FANS FUSE 11 FUSE 42 FUSE/ RELAY PANEL HOT AT ALL TIMES HOT W/ LOAD REDUCTION RELAY ENERGIZED (X) RED WIRE RED/BLU WIRE RED/WHT WIRE SECOND SPEED COOLANT FAN CONTROL RELAY SWITCH

Go to component: -> Cooling fan circuit -> SECOND SPEED COOLANT FAN CONTROL RELAY
