Audi A6 C4 (1994-1997) passenger seat heat regulating switch Wiring diagram
This page shows the only wiring diagram for the component.passenger seat heat regulating switch, which is found in the car Audi A6 C4 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat heat regulating switch (1 of 1)
AUXILIARY RELAY PANEL 1
BLK WIRE
BLU WIRE
BRN WIRE
CENTRAL ELECTRIC PANEL
DRIVER BACKREST HEAT ELEMENT
DRIVER SEAT HEAT ELEMENT
DRIVER SEAT HEAT REGULATING SWITCH
DRIVER SEAT TEMPER- ATURE SENSOR
FUSE 14
FUSE PANEL
HOT AT ALL TIMES HEATED SEAT FUSE 79
HOT IN RUN OR ACC
NCA WIRE
PASSENGER BACKREST HEAT ELEMENT
PASSENGER SEAT HEAT REGULATING SWITCH
PASSENGER SEAT TEMPER- ATURE SENSOR PASSENGER SEAT HEAT ELEMENT
RED WIRE
SOLID STATE
WHT WIRE
YEL WIRE
Go to component -> Front seat heater circuit -> PASSENGER SEAT HEAT REGULATING SWITCH
