Audi A6 C4 (1994-1997) left heated door lock control unit Wiring diagram

This page shows the only wiring diagram for the component.left heated door lock control unit, which is found in the car Audi A6 C4 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left heated door lock control unit (1 of 1)

Wiring diagram left heated door lock control unit for Audi A6 C4 (1994-1997)

Get access

AUXILIARY RELAY PANEL 1 BLK WIRE BLU WIRE BRN WIRE CIRCUIT BREAKER 86 DOOR LOCK SWITCH HOT AT ALL TIMES LEFT DOOR LOCK HEATER LEFT HEATED DOOR LOCK CONTROL UNIT LEFT HEATED DOOR LOCK SWITCH RED WIRE RED/BRN WIRE RIGHT DOOR LOCK HEATER RIGHT HEATED RIGHT HEATED DOOR LOCK CONTROL UNIT

Go to component: -> Heated door locks circuit -> LEFT HEATED DOOR LOCK CONTROL UNIT
