Audi A6 C4 (1994-1997) headlight dimmer/ flasher switch Wiring diagram
This page shows the only wiring diagram for the component.headlight dimmer/ flasher switch, which is found in the car Audi A6 C4 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlight dimmer/ flasher switch (1 of 1)
ABS CONTROL MODULE
AIR BAG CONTROL MODULE, SERVOTRONIC CONTROL MODULE, TRANSMISSION CONTROL MODULE
AUTOMATIC WINDOW CLOSING RELAY
BACK-UP LIGHTS SYSTEM, MIRROR MEMORY CONTROL MODULE
BATTERY
BATTERY JUMP START TERMINAL
BLK WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRN WIRE
CENTRAL ELECTRIC PANEL
CENTRAL LOCKING/ ALARM SYSTEM/ INTERIOR LIGHT DELAY CONTROL MODULE
CENTRAL LOCKING/ ALARM SYSTEM/ INTERIOR LIGHT DELAY CONTROL MODULE, RADIO
CIRCUIT BREAKER 99 FUSE 16
ENGINE CONTROL MODULE
FROM FUSE 14 (DIAGRAM 1 OF 2)
FUEL INJECTORS
FUEL PUMP
FUEL PUMP RELAY
FUSE 14 FUSE 21
FUSE 15
FUSE 17 FUSE 73 FUSE 15
FUSE 8
FUSE 9
FUSE PANEL
GRN WIRE
GRY WIRE
HEADLIGHT DIMMER/ FLASHER SWITCH
HEADLIGHT WASHER SYSTEM RELAY
IGNITION SWITCH
INSTRUMENT CLUSTER
JUMPER (M/T)
KEY-IN IGNITION SWITCH
LIGHT SWITCH GENERATOR, INSTRUMENT CLUSTER
LOCK IND LIGHT, DIFFERENTIAL LOCK CONTROL MODULE
MIRROR ADJUSTMENT SWITCH, INSTRUMENT CLUSTER, OUTSIDE AIR TEMPERATURE DISPLAY
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
OFF
PARK/ NEUTRAL POSITION RELAY (A/T)
RED WIRE
RUN WIRE
STARTER
TO FUSE 10 (DIAGRAM 2 OF 2)
TO LOAD REDUCTION RELAY (DIAGRAM 2 OF 2)
TRANSMISSION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (1 of 2) -> HEADLIGHT DIMMER/ FLASHER SWITCH
