Audi A6 C4 (1994-1997) driver backrest heat element Wiring diagram

This page shows the only wiring diagram for the component.driver backrest heat element, which is found in the car Audi A6 C4 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver backrest heat element (1 of 1)

Wiring diagram driver backrest heat element for Audi A6 C4 (1994-1997)

Get access

AUXILIARY RELAY PANEL 1 BLK WIRE BLU WIRE BRN WIRE CENTRAL ELECTRIC PANEL DRIVER BACKREST HEAT ELEMENT DRIVER SEAT HEAT ELEMENT DRIVER SEAT HEAT REGULATING SWITCH DRIVER SEAT TEMPER- ATURE SENSOR FUSE 14 FUSE PANEL HOT AT ALL TIMES HEATED SEAT FUSE 79 HOT IN RUN OR ACC NCA WIRE PASSENGER BACKREST HEAT ELEMENT PASSENGER SEAT HEAT REGULATING SWITCH PASSENGER SEAT TEMPER- ATURE SENSOR PASSENGER SEAT HEAT ELEMENT RED WIRE SOLID STATE WHT WIRE YEL WIRE

Go to component: -> Front seat heater circuit -> DRIVER BACKREST HEAT ELEMENT
