Audi A6 С6 (2004-2008) sunlight photo sensor Wiring diagram
This page shows the only wiring diagram for the component.sunlight photo sensor, which is found in the car Audi A6 С6 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunlight photo sensor (1 of 1)
BACK PRESSURE FLAP MOTOR, POSITION SENSOR (UNDER RIGHT SIDE OF DASH)
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTER AIR OUTLET SENSOR
CLIMATRONIC CONTROL MODULE
FRESH AIR INTAKE DUCT TEMPERATURE SENSOR (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
LEFT FRONT SEAT TEMPERATURE SENSOR
NCA WIRE
REAR WINDOW SHADE SWITCH
RECIRCULATION FLAP MOTOR, POSITION SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SUNLIGHT PHOTO SENSOR
VIO/GRN WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component: -> Automatic a/c circuit (3 of 4) -> SUNLIGHT PHOTO SENSOR
