Audi A6 С6 (2004-2008) rear window glass breakage sensor Wiring diagrams

This page contains all the electrical diagrams for the component. rear window glass breakage sensor, in which he is found in the car Audi A6 С6 (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear window glass breakage sensor (1 of 2)

Wiring diagram rear window glass breakage sensor for Audi A6 С6 (2004-2008)

Get access

ALARM HORN ALARM SYSTEM OFF SWITCH BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE CENTRAL LOCKING WARNING LIGHT (SAFE) DRIVER'S INTERIOR LOCKING SWITCH FRONT PASSENGER'S INTERIOR LOCKING SWITCH FUSE FUSE 39 GLOVEBOX UNLOCK MOTOR GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRY WIRE GRY/GRN WIRE HOT AT ALL TIMES INTERIOR LIGHTS, MIRRORS, MEMORY, POWER WINDOWS SYSTEM INTERIOR LIGHTS, POWER WINDOWS SYSTEM LEFT REAR INTERIOR LOCKING SWITCH LEFT REAR WINDOW BREAKAGE SENSOR REAR CENTRAL LOCKING MOTOR, ALARM SWITCH REAR WINDOW GLASS BREAKAGE SENSOR RED WIRE RED/GRN WIRE RED/GRY WIRE RIGHT REAR WINDOW BREAKAGE SENSOR TRUNK LOCK ALARM/ CENTRAL LOCKING SWITCH VIO WIRE VIO/BLU WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> Forced entry circuit (2 of 3) -> REAR WINDOW GLASS BREAKAGE SENSOR
