Audi A6 С6 (2004-2008) radio/telephone/ navigation antenna Wiring diagrams

This page contains all the electrical diagrams for the component. radio/telephone/ navigation antenna, in which he is found in the car Audi A6 С6 (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram radio/telephone/ navigation antenna (1 of 2)

Wiring diagram radio/telephone/ navigation antenna for Audi A6 С6 (2004-2008)

Get access

BLK WIRE BLU WIRE BRN WIRE CD CHANGER UNIT OR MEDIA PLAYER, POSITION 1 CD CHANGER UNIT OR MEDIA PLAYER, POSITION 2 COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE FUSE FUSE 12 FUSE 5 FUSE 7 FUSE 8 FUSE 9 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE NCA WIRE RADIO RADIO/TELEPHONE/ NAVIGATION ANTENNA RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/YEL WIRE SATELLITE RADIO SOUND SYSTEM (MOST DATA BUS CIRCUIT) SPEECH INPUT CONTROL MODULE (IF EQUIPPED) UPPER LEFT REAR WINDOW AMPLIFIER ANTENNA YEL WIRE

Go to component: -> Front information display control module circuit (2 of 2) -> RADIO/TELEPHONE/ NAVIGATION ANTENNA

Wiring diagram radio/telephone/ navigation antenna (2 of 2)

Wiring diagram radio/telephone/ navigation antenna for Audi A6 С6 (2004-2008)

Get access

BLK WIRE BLU WIRE BRN WIRE CD CHANGER UNIT OR MEDIA PLAYER, POSITION 1 CD CHANGER UNIT OR MEDIA PLAYER, POSITION 2 COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE FUSE FUSE 12 FUSE 5 FUSE 7 FUSE 8 FUSE 9 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE NCA WIRE RADIO RADIO/TELEPHONE/ NAVIGATION ANTENNA RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/YEL WIRE SATELLITE RADIO SOUND SYSTEM (MOST DATA BUS CIRCUIT) SPEECH INPUT CONTROL MODULE (IF EQUIPPED) UPPER LEFT REAR WINDOW AMPLIFIER ANTENNA YEL WIRE

Go to component: -> Front information display control module circuit (2 of 2) -> RADIO/TELEPHONE/ NAVIGATION ANTENNA
