Audi A6 С6 (2004-2008) left footwell flap motor, position sensor Wiring diagram

A/C COMPRESSOR REGULATOR VALVE A/C PRESSURE/ TEMPERATURE SENSOR AIR QUALITY SENSOR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/WHT/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL VENT MOTOR, POSITION SENSOR CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM FRONT COLD AIR FLAP MOTOR, POSITION SENSOR GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HEAT REGULATING VALVE, COOLANT PUMP INDIRECT VENTILATION FLAP MOTOR, POSITION SENSOR LEFT FOOTWELL FLAP MOTOR, POSITION SENSOR ORG/BRN WIRE ORG/GRN WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FOOTWELL FLAP MOTOR, POSITION SENSOR RIGHT FRONT UPPER BODY OUTET POSITION SENSOR SEATS SYSTEM (HEATED SEATS CIRCUIT) SEATS SYSTEM (HEATED SEATS CIRCUIT) VIO WIRE VIO/GRN WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE
