Audi A6 С6 (2004-2008) left child safety button Wiring diagram
This page shows the only wiring diagram for the component.left child safety button, which is found in the car Audi A6 С6 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left child safety button (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR POWER WINDOW CONTROL HEAD
DRIVER'S SIDE DOOR CONTROL MODULE (IN DRIVER'S DOOR)
DRIVER'S SIDE WINDOW REGULATOR MOTOR
FUSE 39
FUSE PANEL B FUSE 44
GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS, DOOR LOCKS SYSTEM
INTERIOR LIGHTS, DOOR LOCKS,, MIRRORS SYSTEM
LEFT CHILD SAFETY BUTTON
LEFT FRONT WINDOW REGULATOR SWITCH
LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR)
LEFT REAR WINDOW REGULATOR MOTOR
LEFT REAR WINDOW REGULATOR SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT CHILD SAFETY BUTTON
RIGHT FRONT WINDOW REGULATOR SWITCH
RIGHT REAR WINDOW REGULATOR SWITCH
W/ REAR ASHTRAY
WHT/YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit (1 of 2) -> LEFT CHILD SAFETY BUTTON
