Audi A6 С6 (2004-2008) driver side door opener lighting Wiring diagram
This page shows the only wiring diagram for the component.driver side door opener lighting, which is found in the car Audi A6 С6 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side door opener lighting (1 of 1)
ALARM SYSTEM OFF SWITCH
BLU WIRE
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE DOOR CONTROL MODULE
DRIVER SIDE DOOR OPENER LIGHTING
DRIVER SIDE INTERIOR LOCK SWITCH
DRIVER'S SEAT MEMORY PROGRAM SWITCH
GRY WIRE
LEFT REAR ASHTRAY LIGHT
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR OPENER LIGHT
LEFT REAR INTERIOR SWITCH
LEFT REAR WINDOW SWITCH
MIRROR ADJUSTMENT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER DOOR CONTROL MODULE
PASSENGER DOOR WINDOW REGULATOR SWITCH
PASSENGER SIDE INTERIOR LOCK SWITCH
POWER WINDOWS, DOOR LOCKS, COURTESY LIGHTS CIRCUIT
POWER WINDOWS, MIRRORS, DOOR LOCKS SYSTEMS, COURTESY LAMPS CIRCUIT
REAR LID RELEASE SWITCH
RED WIRE
RED/GRY WIRE
RIGHT REAR ASHTRAY LIGHT
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR OPENER LIGHT
RIGHT REAR INTERIOR SWITCH
RIGHT REAR WINDOW SWITCH
Go to component: -> Instrument illumination circuit (2 of 2) -> DRIVER SIDE DOOR OPENER LIGHTING
