Audi A6 С6 (2004-2008) access/start control module Wiring diagrams
This page contains all the electrical diagrams for the component. access/start control module, in which he is found in the car Audi A6 С6 (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram access/start control module (1 of 2)
4.2L 3.2L
ACCESS/START AUTHORIZATION SWITCH
ACCESS/START CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE
FUSE 31
FUSE HOLDER FUSE 20
FUSE PANEL B
FUSE PANEL C
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY ENERGIZED
INSTRUMENT CLUSTER
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/VIO WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE (TR) POSITION DISPLAY
SHIFT LOCK SOLENOID
TRANSMISSION CONTROLS MODULE (TCM) (UNDER PASSENGER'S SEAT)
TRANSMISSION PARK SELECTOR SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
Go to component -> A/t circuit, 6 speed a/t -> ACCESS/START CONTROL MODULE
Wiring diagram access/start control module (2 of 2)
