Audi A6 С6 (2004-2008) 3.2l w/o coolant fan electronics Wiring diagram

This page shows the only wiring diagram for the component.3.2l w/o coolant fan electronics, which is found in the car Audi A6 С6 (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 3.2l w/o coolant fan electronics (1 of 1)

Wiring diagram 3.2l w/o coolant fan electronics for Audi A6 С6 (2004-2008)

Get access

3.2L 3.2L W/O COOLANT FAN ELECTRONICS 4.2L AFTER-RUN COOLANT PUMP BLU/VIO WIRE BRN WIRE COOLANT FAN CONTROL MODULE ENGINE CONTROL MODULE (ECM) (3.2L) ENGINE CONTROL MODULE (ECM) (4.2L) ENGINE CONTROLS SYSTEM FUSE 104 FUSE 13 FUSE 19 FUSE 42 FUSE HOLDER GRY/BLU WIRE HOT AT ALL TIMES HOT W/ ECM RELAY ENERGIZED MAIN FUSE PANEL RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SUPPRESSOR

Go to component: -> Cooling fan circuit -> 3.2L W/O COOLANT FAN ELECTRONICS
