Audi A6 Allroad Quattro C8 (2019-2024) Parking assistant circuit, w/ parallel parking & driver assistance

BLK WIRE BLK/YEL WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER ASSISTANCE SYSTEMS CONTROL MODULE FRONT PARKING AID WARNING BUZZER FUSE 1 FUSE 9 FUSE PANEL B FUSE PANEL M GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT BUMPER COUPLING POINT LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR ORG/ WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR VIO/BLU WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/GRY WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/GRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM FUSE 5 FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT REAR BUMPER COUPLING POINT LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR LEFT REAR PARKING AID SENSOR ORG/ WIRE PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR RIGHT REAR PARKING AID SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE WHT/BLK WIRE WHT/GRN WIRE YEL/GRY WIRE YEL/RED WIRE
