Audi A6 Allroad Quattro C8 (2019-2024) Headlights circuit, w/ multiple matrix beam
Headlights circuit, w/ multiple matrix beam (1 of 3)
ABS CONTROL MODULE
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
AUTOMATIC HIGH BEAM BUTTON
BLU WIRE
BRN WIRE
BRN/YEL WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON ROOF
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 12
FUSE 3
FUSE 5
FUSE 9
FUSE PANEL B
FUSE PANEL D
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HUMIDITY SENSOR
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR REAR VIEW MIRROR
LEFT FRONT LEVEL CONTROL SYSTEM SENSOR
LEFT REAR LEVEL CONTROL SYSTEM SENSOR
LIGHT RECOGNITION SENSOR
LIGHT SWITCH
ORG/BRN WIRE
PARKING BRAKE BUTTON
PARKING BRAKE INDICATOR
PNK WIRE
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Headlights circuit, w/ multiple matrix beam (2 of 3)
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRY WIRE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT DYNAMIC TURN SIGNAL
LEFT FRONT HEADLAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP 12 PIN CONNECTOR
LEFT HEADLAMP 16-PIN CONNECTOR
LEFT HEADLAMP 24-PIN CONNECTOR
LEFT HEADLAMP 4 PIN CONNECTOR
LEFT HEADLAMP FAN
LEFT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HEADLAMP TEMPERATURE SENSOR 4
LEFT HIGH BEAM HEADLAMP
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LED HEADLAMP POWER OUTPUT MODULE 2
LEFT LOW BEAM HEADLAMP
LEFT MATRIX HEADLAMP POWER OUTPUT MODULE
LEFT STATIONARY CORNERING LAMP
ORG/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
Headlights circuit, w/ multiple matrix beam (3 of 3)
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRY WIRE
ORG/BRN WIRE
RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
RIGHT FRONT DYNAMIC TURN SIGNAL
RIGHT FRONT HEADLAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP 12 PIN CONNECTOR
RIGHT HEADLAMP 16-PIN CONNECTOR
RIGHT HEADLAMP 24-PIN CONNECTOR
RIGHT HEADLAMP 4 PIN CONNECTOR
RIGHT HEADLAMP FAN
RIGHT HEADLAMP RANGE CONTROL ADJUSTMENT MOTOR
RIGHT HEADLAMP TEMPERATURE SENSOR 1
RIGHT HEADLAMP TEMPERATURE SENSOR 2
RIGHT HEADLAMP TEMPERATURE SENSOR 3
RIGHT HEADLAMP TEMPERATURE SENSOR 4
RIGHT HIGH BEAM HEADLAMP
RIGHT LED HEADLAMP POWER OUTPUT MODULE 1
RIGHT LED HEADLAMP POWER OUTPUT MODULE 2
RIGHT LOW BEAM HEADLAMP
RIGHT MATRIX HEADLAMP POWER OUTPUT MODULE
RIGHT STATIONARY CORNERING LAMP
WHT/RED WIRE
