Audi A6 Allroad Quattro C8 (2019-2024) seat depth adjustment sensor Wiring diagram
This page shows the only wiring diagram for the component.seat depth adjustment sensor, which is found in the car Audi A6 Allroad Quattro C8 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat depth adjustment sensor (1 of 1)
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST ADJUSTMENT SWITCH
DRIVER MULTI-CONTOUR SEAT COMPRESSOR
DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT ANGLE ADJUSTMENT MOTOR
DRIVER SEAT ANGLE ADJUSTMENT SWITCH
DRIVER SEAT COUPLING POINT
DRIVER SEAT DEPTH ADJUSTMENT MOTOR
DRIVER SEAT DEPTH ADJUSTMENT SENSOR, DRIVER SEAT DEPTH ADJUSTMENT MOTOR
DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH
DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT SENSOR
DRIVER SEAT HEIGHT ADJUSTMENT SENSOR, DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT SWITCH
DRIVER SEAT TILT ADJUSTMENT SENSOR
DRIVER SEAT TILT ADJUSTMENT SENSOR, DRIVER SEAT ANGLE ADJUSTMENT MOTOR
DRIVER SEAT VALVE BLOCK 1
DRIVER SEAT VALVE BLOCK 2
GRN/BRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
SEAT DEPTH ADJUSTMENT SENSOR
VIO WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Driver"s memory seat circuit, w/ comfort seats (1 of 2) -> SEAT DEPTH ADJUSTMENT SENSOR
