Audi A6 Allroad Quattro C8 (2019-2024) left front reading lamp Wiring diagram
This page shows the only wiring diagram for the component.left front reading lamp, which is found in the car Audi A6 Allroad Quattro C8 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front reading lamp (1 of 1)
BLK WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER
COMPUTER DATA LINES SYSTEM
DATA LINES
DRIVER SEAT COUPLING POINT
DRIVER VANITY MIRROR LAMP
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
EMERGENCY CALL BUTTON
FRONT INTERIOR LAMP BUTTON
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
FRONT ROOF MODULE
FUSE 13
FUSE PANEL B
GRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
LEFT REAR FOOTWELL LAMP
LEFT REAR READING LAMP
LEFT REAR READING LAMP SWITCH
ORG/BRN WIRE
REAR INTERIOR LIGHT (IF EQUIPPED)
REAR READING LAMP FRONT BUTTON
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
RIGHT REAR FOOTWELL LAMP
RIGHT REAR READING LAMP
RIGHT REAR READING LAMP SWITCH
ROAD SIDE ASSISTANCE BUTTON
ROOF ELECTRONICS CONTROL MODULE
SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/RED WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit (6 of 6) -> LEFT FRONT READING LAMP
