Audi A6 Allroad Quattro C8 (2019-2024) front passenger interior locking button Wiring diagrams

BLK/GRN WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER CENTRAL LOCKING SAFE MOTOR FRONT PASSENGER CLOSING AID MOTOR FRONT PASSENGER DOOR CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR EMERGENCY UNLOCK SWITCH FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER EXTERIOR DOOR HANDLE SWITCH FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER SIDE CENTRAL LOCKING MOTOR FRONT PASSENGER SIDE INTERIOR DOOR HANDLE SWITCH FUSE 14 FUSE 5 FUSE PANEL B GRN WIRE GRY/GRN WIRE HOT AT ALL TIMES ORG/BRN WIRE PASSENGER FRONT DOOR) RED WIRE RED/WHT WIRE RIGHT FRONT DOOR COUPLING POINT VIO/BLU WIRE VIO/RED WIRE W/ SAFE FUNCTION W/ DOOR CLOSING AID WHT/GRN WIRE YEL/BLK WIRE YEL/GRN WIRE

BLK/WHT WIRE BLU/BRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR POWER WINDOW SWITCH FRONT PASSENGER EXIT WARNING LAMP FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER SEAT MEMORY SETTINGS CONTROL HEAD FUSE 14 FUSE 5 FUSE 7 FUSE PANEL B FUSE PANEL D GRN WIRE HOT AT ALL TIMES ORG/BRN WIRE PASSENGER SIDE DOOR AMBIENT LIGHTING LAMP PASSENGER SIDE DOOR SPEAKER TRIM LAMP PASSENGER SIDE ENTRY LAMP PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP PASSENGER SIDE REAR DOOR PASSENGER SIDE REAR DOOR AMBIENT LIGHT LAMP PASSENGER SIDE REAR DOOR CONTROL HEAD PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR DOOR SPEAKER TRIM LAMP PASSENGER SIDE REAR ENTRY LAMP PASSENGER SIDE REAR EXIT WARNING LAMP PASSENGER SIDE REAR INTERIOR DOOR HANDLE ILLUMINATION LAMP PASSENGER SIDE REAR INTERIOR LOCKING BUTTON RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT DOOR COUPLING POINT RIGHT REAR DOOR COUPLING POINT RIGHT REAR INTERIOR LOCKING INDICATOR LAMP W/ BANG, OLUFSEN SOUND SYSTEM

BLK/GRN WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER CENTRAL LOCKING SAFE MOTOR FRONT PASSENGER CLOSING AID MOTOR FRONT PASSENGER DOOR CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR EMERGENCY UNLOCK SWITCH FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER EXTERIOR DOOR HANDLE SWITCH FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER SIDE CENTRAL LOCKING MOTOR FRONT PASSENGER SIDE INTERIOR DOOR HANDLE SWITCH FUSE 14 FUSE 5 FUSE PANEL B GRN WIRE GRY/GRN WIRE HOT AT ALL TIMES ORG/BRN WIRE PASSENGER FRONT DOOR) RED WIRE RED/WHT WIRE RIGHT FRONT DOOR COUPLING POINT VIO/BLU WIRE VIO/RED WIRE W/ SAFE FUNCTION W/ DOOR CLOSING AID WHT/GRN WIRE YEL/BLK WIRE YEL/GRN WIRE
