Audi A6 Allroad Quattro C8 (2019-2024) dual exhaust temperature sensor 1 Wiring diagram

ACCELERATOR PEDAL MODULE (AT ACCELERATOR PEDAL) ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/RED WIRE CHARGE AIR PRESSURE SENSOR COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DUAL EXHAUST TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE/MOTOR CONTROL MODULE EXHAUST GAS TEMPERATURE SENSOR 3 EXHAUST GAS TEMPERATURE SENSOR 4 GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE PARTICULATE FILTER DIFFERENTIAL PRESSURE SENSOR PNK WIRE PNK/WHT WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE STARTING/CHARGING SYSTEM TANK VENTILATION PRESSURE SENSOR 1 TRANSMISSIONS SYSTEM VIO WIRE VIO/GRY WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/VIO WIRE
