Audi A6 Allroad Quattro C8 (2019-2024) driver side rear seat occupant detection sensor Wiring diagram
This page shows the only wiring diagram for the component.driver side rear seat occupant detection sensor, which is found in the car Audi A6 Allroad Quattro C8 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side rear seat occupant detection sensor (1 of 1)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER AIR BAG IGNITER
DRIVER AIR BAG RELEASE VALVE IGNITER
DRIVER BELT FORCE LIMITER
DRIVER KNEE AIR BAG IGNITER
DRIVER SEAT BELT TENSIONER IGNITER 1
DRIVER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
FRONT PASSENGER AIR BAG UNIT (RIGHT SIDE OF DASH)
FRONT PASSENGER BELT FORCE LIMITER
FRONT PASSENGER KNEE AIR BAG IGNITER
FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1
GRN WIRE
GRY WIRE
HORNS SYSTEM
IGNITER 1
IGNITER 2
LEFT FRONT SEAT BELT
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
ORG/BRN WIRE
PASSENGER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
REAR CENTER SEAT OCCUPANT DETECTION SENSOR
REAR SEAT COUPLING POINT
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELEASE VALVE IGNITER
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (4 of 5) -> DRIVER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
