Audi A6 Allroad Quattro C8 (2019-2024) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi A6 Allroad Quattro C8 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (181 of 210)
BLK/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPLING STATION IN LEFT FRONT SEAT
DRIVER BACKREST HEATING ELEMENT
DRIVER HEATED SEAT EXTENSION
DRIVER SEAT BOLSTER HEATER
DRIVER SEAT COUPLING POINT
FUSE 10
FUSE PANEL D (LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT TEMPERATURE SENSOR DRIVER SEAT HEATING ELEMENT
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Front heated seats circuit, w/o ventilation w/ sport seats (1 of 2) -> BRN WIRE
Wiring diagram brn (182 of 210)
BLK/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPLING STATION IN RIGHT FRONT SEAT
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER HEATED SEAT EXTENSION
FRONT PASSENGER SEAT BOLSTER HEATER
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT HEATING ELEMENT
FRONT PASSENGER SEAT TEMPERATURE SENSOR
GRN WIRE
LEFT SEAT HEATING BUTTON
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RIGHT SEAT HEATING BUTTON
WHT WIRE
WHT/VIO WIRE
Go to component -> Front heated seats circuit, w/o ventilation w/ sport seats (2 of 2) -> BRN WIRE
Wiring diagram brn (183 of 210)
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPLING STATION IN LEFT FRONT SEAT
COUPLING STATION IN RIGHT FRONT SEAT
DRIVER BACKREST HEATING ELEMENT
DRIVER SEAT COUPLING POINT
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT HEATING ELEMENT
FRONT PASSENGER SEAT TEMPERATURE SENSOR
FUSE 10
FUSE PANEL D (LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT TEMPERATURE SENSOR DRIVER SEAT HEATING ELEMENT
LEFT SEAT HEATING BUTTON
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT SEAT HEATING BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Front heated seats circuit, w/o ventilation w/ standard & comfort seats -> BRN WIRE
Wiring diagram brn (184 of 210)
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
COUPLING STATION IN RIGHT FRONT SEAT
DRIVER SEAT BACKREST BLOWER FAN
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT COUPLING POINT
FRONT PASSENGER BACKREST HEATING ELEMENT
FRONT PASSENGER SEAT BACKREST COUPLING POINT
FRONT PASSENGER SEAT BOLSTER HEATER
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT HEATING ELEMENT
FRONT PASSENGER SEAT TEMPERATURE SENSOR
GRN WIRE
LEFT FRONT SEAT CUSHION FAN 1
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT SEAT BACKREST FAN 1
RIGHT FRONT SEAT CUSHION FAN 1
VIO/BLU WIRE
VIO/WHT WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Front heated seats circuit, w/ ventilation (2 of 2) -> BRN WIRE
Wiring diagram brn (185 of 210)
ANGLE
BACKREST
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FORWARD /BACK
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT BACKREST COUPLING POINT
FRONT PASSENGER SEAT FORWARD/ BACK ADJUSTMENT MOTOR
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR
GRN WIRE
GRY WIRE
HEIGHT
HOT AT ALL TIMES
RED WIRE
W/ SEAT VENTILATION
W/O SEAT VENTILATION
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> BRN WIRE
Wiring diagram brn (186 of 210)
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COUPLING POINT IN LEFT REAR SEAT
COUPLING POINT IN RIGHT REAR SEAT
DRIVER SIDE REAR SEAT TEMPERATURE SENSOR
FUSE 4
FUSE PANEL J
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT
LEFT REAR SEAT COUPLING STATION
PASSENGER SIDE REAR SEAT TEMPERATURE SENSOR
REAR A/C DISPLAY CONTROL HEAD
RED WIRE
RED/WHT WIRE
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR BENCH SEAT HEATING ELEMENT
RIGHT REAR SEAT COUPLING STATION
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Rear heated seats circuit -> BRN WIRE
Wiring diagram brn (187 of 210)
AIR BAG CONTROL MODULE
AIR BAG INDICATOR LAMP
BATTERY INTERRUPT IGNITER
BATTERY MONITORING CONTROL MODULE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER HEAD CURTAIN AIR BAG IGNITER
DRIVER SEAT BELT SWITCH
DRIVER SEAT COUPLING POINT
DRIVER SEAT POSITION SENSOR
ENGINE CONTROLS SYSTEM
FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER
FUSE 10
FUSE 3
FUSE 4
FUSE 7
FUSE PANEL F
FUSE PANEL H
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Supplemental restraints circuit (1 of 5) -> BRN WIRE
Wiring diagram brn (188 of 210)
4.0L TURBO HYBRID
AIR BAG CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT AIR BAG CRASH SENSOR
DRIVER SEAT BELT TENSIONER IGNITER 2
DRIVER SIDE REAR THORAX AIR BAG CRASH SENSOR
DRIVER THORAX AIR BAG CRASH SENSOR
EXCEPT 4.0L TURBO HYBRID
FRONT PASSENGER THORAX AIR BAG CRASH SENSOR
GRN WIRE
GRN/WHT WIRE
GRY WIRE
LEFT FRONT BUMPER COUPLING POINT
LEFT FRONT DOOR COUPLING POINT
ORG/BRN WIRE
PASSENGER SIDE FRONT AIR BAG CRASH SENSOR
PASSENGER SIDE REAR THORAX AIR BAG CRASH SENSOR
PNK WIRE
PNK/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT BUMPER COUPLING POINT
RIGHT FRONT DOOR COUPLING POINT
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (3 of 5) -> BRN WIRE
Wiring diagram brn (189 of 210)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER AIR BAG IGNITER
DRIVER AIR BAG RELEASE VALVE IGNITER
DRIVER BELT FORCE LIMITER
DRIVER KNEE AIR BAG IGNITER
DRIVER SEAT BELT TENSIONER IGNITER 1
DRIVER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
FRONT PASSENGER AIR BAG UNIT (RIGHT SIDE OF DASH)
FRONT PASSENGER BELT FORCE LIMITER
FRONT PASSENGER KNEE AIR BAG IGNITER
FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1
GRN WIRE
GRY WIRE
HORNS SYSTEM
IGNITER 1
IGNITER 2
LEFT FRONT SEAT BELT
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
ORG/BRN WIRE
PASSENGER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
REAR CENTER SEAT OCCUPANT DETECTION SENSOR
REAR SEAT COUPLING POINT
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELEASE VALVE IGNITER
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (4 of 5) -> BRN WIRE
Wiring diagram brn (190 of 210)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SEAT COUPLING POINT
DRIVER SIDE REAR SEAT BELT TENSIONER IGNITER
DRIVER SIDE REAR THORAX AIR BAG IGNITER
DRIVER THORAX AIR BAG IGNITER
ENGINE CONTROLS SYSTEM
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER THORAX AIR BAG IGNITER
FUSE 10
FUSE 16
FUSE PANEL B
FUSE PANEL M
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR SEAT BELT TENSIONER CONTROL MODULE
ORG/BRN WIRE
PASSENGER SIDE REAR SEAT BELT TENSIONER IGNITER
PASSENGER SIDE REAR THORAX AIR BAG IGNITER
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT REAR SEAT BELT TENSIONER CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (5 of 5) -> BRN WIRE
