Brake wear sensor circuit for Audi A5 II (2016-2020)
Brake wear sensor circuit
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT INSTRUMENT CLUSTER CONTROL MODULE
FUSE 9
FUSE PANEL 3
FUSE PANEL B
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT BRAKE PAD WEAR SENSOR
ORG/BRN WIRE
RED WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 1
RIGHT REAR BRAKE PAD WEAR SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
