Car Wiring Diagrams for Charging circuit for Audi A5 I (2007-2011)

BATTERY BATTERY INTERRUPT IGNITER BATTERY JUMP START TERMINAL (ON TERMINAL 30 WIRE JUNCTION BLOCK) BATTERY MONITORING CONTROL MODULE (AT BATTERY) BLK WIRE BLU WIRE BRN WIRE DATA BUS ON BOARD DIAGNOSTIC INTERFACE (ABOVE GLOVE BOX) GENERATOR, VOLTAGE REGULATOR MAIN FUSE PANEL SA (ON BATTERY, IN LUGGAGE COMPT) RED WIRE RED/BRN WIRE STARTER SUPPLEMENTAL RESTRAINTS SYSTEM VIO/BLU WIRE WHT WIRE
