Audi A5 I (2007-2011) right front entry light Wiring diagram
This page shows the only wiring diagram for the component.right front entry light, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front entry light (1 of 1)
AUTOMATIC DAY/ NIGHT INTERIOR MIRROR
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTACT SWITCH
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
DRIVER'S DOOR WARNING LIGHT
DRIVER'S MAP/ READING LIGHT
DRIVER'S READING LIGHT BUTTON
FRONT INTERIOR LAMP ASSEMBLY
FRONT INTERIOR LIGHT
FRONT PASSENGER'S DOOR CONTACT SWITCH
FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S FRONT DOOR)
FRONT PASSENGER'S DOOR WARNING LIGHT
FRONT PASSENGER'S MAP/ READING LIGHT
FRONT PASSENGER'S READING LIGHT BUTTON
GRN WIRE
GRY WIRE
GRY/VIO WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR ILLUMINATION SWITCH
LEFT FRONT ENTRY LIGHT
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT ENTRY LIGHT
RIGHT REAR INTERIOR LIGHT
RIGHT REAR READING LIGHT SWITCH 1
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT FRONT ENTRY LIGHT
