Audi A5 I (2007-2011) lamp/drl module right led parking Wiring diagram
This page shows the only wiring diagram for the component.lamp/drl module right led parking, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lamp/drl module right led parking (1 of 1)
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 7 FUSE 6
FUSE CARRIER 1
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEADLIGHT RANGE/ CORNERING LAMP CONTROL MODULE (ABOVE GLOVE BOX)
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LAMP
LAMP/DRL MODULE RIGHT LED PARKING
LEFT FRONT FOG LAMP
LEFT FRONT LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING)
LEFT REAR LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING) (AT LEFT REAR
MARKER LAMP
ORG/BLK WIRE
ORG/BRN WIRE
RIGHT DYNAMIC CORNERING LIGHT MOTOR
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HEADLIGHT ASSEMBLY
RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP
RIGHT HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT PARKING
SIDE OF REAR AXLE)
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Headlights circuit, with bi-xenon with cornering headlights (2 of 2) -> LAMP/DRL MODULE RIGHT LED PARKING
