Audi A5 I (2007-2011) ground computer data distribution lines system system Wiring diagram
This page shows the only wiring diagram for the component.ground computer data distribution lines system system, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground computer data distribution lines system system (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPT SF (RIGHT SIDE OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL MODULE (IN LEFT FRONT DOOR)
DRIVER'S DOOR POWER WINDOW CONTROL HEAD
DRIVER'S WINDOW REGULATOR MOTOR
FRONT PASSENGER'S DOOR CONTROL MODULE (IN RIGHT FRONT DOOR)
FRONT PASSENGER'S WINDOW REGULATOR MOTOR
FRONT PASSENGER'S WINDOW REGULATOR SWITCH
FUSE 11
FUSE 8
FUSE 9
FUSE CARRIER 2 FUSE 8
FUSE CARRIER 2 FUSE 8 FUSE 11
FUSE CARRIER 3
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/WHT WIRE
GROUND COMPUTER DATA DISTRIBUTION LINES SYSTEM SYSTEM
GROUND DISTRIBUTION SYSTEM
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT RIGHT FRONT WINDOW WINDOW REGULATOR REGULATOR SWITCH SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
REAR WINDOW SHADE MOTOR (IF EQUIPPED)
REAR WINDOW SHADE SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY/ FUSE CARRIER LUGGAGE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL)
VIO WIRE
VIO/BLK WIRE
W/ ADDITIONAL EQUIPMENT
W/O NAVIGATION SYSTEM W/ NAVIGATION SYSTEM
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power windows circuit -> GROUND COMPUTER DATA DISTRIBUTION LINES SYSTEM SYSTEM
