Audi A5 I (2007-2011) front passenger's lane change assistance warning lamp Wiring diagram
This page shows the only wiring diagram for the component.front passenger's lane change assistance warning lamp, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's lane change assistance warning lamp (1 of 1)
BLK/BRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE CONTROL MODULE
DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD HEATER
DRIVER'S LANE CHANGE ASSISTANCE WARNING LAMP
FRONT PASSENGER'S LANE CHANGE ASSISTANCE WARNING LAMP
FUSE CARRIER 1 FUSE 4
FUSE CARRIER 4 FUSE 10
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GRY/BLU WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LANE CHANGE ASSISTANCE BUTTON
LANE CHANGE ASSISTANCE CONTROL MODULE (BEHIND RIGHT SIDE OF REAR BUMPER)
LANE CHANGE ASSISTANCE CONTROL MODULE 2 (BEHIND LEFT SIDE OF REAR BUMPER)
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
RELAY/FUSE CARRIER LUGGAGE COMPARTMENT SF
VIO/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Lane departure warning circuit -> FRONT PASSENGER'S LANE CHANGE ASSISTANCE WARNING LAMP
