Audi A5 I (2007-2011) from motronic engine Wiring diagram
This page shows the only wiring diagram for the component.from motronic engine, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from motronic engine (1 of 1)
17 PIN CONNECTOR (NOT USED)
3.2L
3.2L 4.2L
4.2L
4.2L 3.2L
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
CARRIER E- BOX SB (IN LEFT PLENUM CHAMBER E-BOX)
CONTROL MODULE (ECM) POWER SUPPLY RELAY (DIAGRAM 2 OF 7)
E-BOX-SB)
ENGINE COMPONENT POWER SUPPLY RELAY (ON RELAY/ FUSE CARRIER
ENGINE CONTROL MODULE (ECM)
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE REGULATOR VALVE
FROM MOTRONIC ENGINE
FROM MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY (DIAGRAM 2 OF 7)
FROM POWER SUPPLY RELAY (TERMINAL 15) (DIAGRAM 1 OF 7)
FUEL FUEL METERING METERING VALVE 2 VALVE (4.2L)
FUSE
FUSE 10
FUSE FUSE
FUSE FUSE FUSE
GRN RED/ WIRE
GRN WIRE
GRN/YEL WIRE
GRY/YEL WIRE
HEATER 2
IGNITION COIL 3 W/POWER OUTPUT STAGE
INTAKE AIR SWITCH OVER VALVE (4.2L)
LEAK DETECTION PUMP (LDP)
LEFT ELECTRO HYDRAULIC ENGINE MOUNT SOLENOID VALVE (4.2L)
MASS AIR FLOW (MAF) SENSOR (4.2L)
NCA WIRE
OIL LEVEL ENGINE CONTROL THERMAL MODULE (ECM) SENSOR
OIL PRESSURE REGULATION VALVE (3.2L)
OXYGEN SENSOR
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY/ FUSE
RIGHT ELECTRO HYDRAULIC ENGINE MOUNT SOLENOID VALVE (4.2L)
STARTER RELAY
STARTER RELAY 2
TO FUSE PANEL SC (DIAGRAM 7 OF 7)
TO INTAKE FLAP MOTOR (DIAGRAM 6 OF 7)
TRANSMISSION DIRECT SHIFT CONTROL GEARBOX (DSG) MODULE MECHATRONIC (TCM)
TWC HEATER OXYGEN SENSOR 2
TWC OXYGEN SENSOR 1
VIO WIRE
W/ DIRECT W/O DIRECT SHIFT SHIFT GEAR BOX GEAR BOX
WHT RED/ WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (5 of 7) -> FROM MOTRONIC ENGINE
