Audi A5 I (2007-2011) electro- mechanical parking brake control module Wiring diagrams
This page contains all the electrical diagrams for the component. electro- mechanical parking brake control module, in which he is found in the car Audi A5 I (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram electro- mechanical parking brake control module (1 of 2)
ACCESS/START AUTHORIZATION SWITCH
AUXILIARY HEATER CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT)
CLIMATRONIC CONTROL MODULE
ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
EXTERNAL AUDIO SOURCE CONNECTION
FRONT PASSENGER'S DOOR CONTROL MODULE (IN PASSENGER'S FRONT DOOR)
GRN/VIO WIRE
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PARALLEL PARKING ASSISTANCE CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
PASSENGER'S MEMORY SEAT CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT)
PASSENGER'S SIDE CAN SEPARATING PLUG
RADIO
STEERING COLUMN ELECTRONIC SYSTEM CONTROL MODULE
TIRE PRESSURE MONITORING CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
VIO/BLU WIRE
VIO/YEL WIRE
W/ MMI HIGH
Go to component -> Computer data lines circuit (3 of 3) -> ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
Wiring diagram electro- mechanical parking brake control module (2 of 2)
12 PIN CONNECTOR (NOT USED)
18-PIN CONNECTOR (NOT USED)
ALL- WHEEL DRIVE CONTROL MODULE
BLU/RED WIRE
CARRIER LUGGAGE COMPART- MENT SF (RIGHT SIDE OF
COMFORT SYSTEM CENTRAL CONTROL MODULE
DISCONTINUED PHASED IN MODIFICATION
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
ELECTRONIC DAMPING CONTROL MODULE
FROM MAIN FUSE PANEL SA (DIAGRAM 1 OF 7)
FUSE
FUSE 11
FUSE 3 FUSE 6 FUSE FUSE 4 FUSE 5
FUSE CARRIER 1
FUSE CARRIER 2 FUSE 12
FUSE CARRIER 3 FUSE 11 FUSE 12 FUSE FUSE 10
FUSE CARRIER 5 FUSE FUSE
FUSE FUSE
FUSE FUSE 1 FUSE
FUSE FUSE FUSE
FUSE FUSE FUSE FUSE FUSE
GRN/RED WIRE
LUGGAGE COMPT)
NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE
NCA WIRE
PHASED IN MODIFICATION
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY/ FUSE
SATELLITE RADIO (K-BOX) RADIO
TELEPHONE TRANSCEIVER
TIRE PRESSURE MONITORING CONTROL MODULE
TO CONVERTER W/ SOCKET
TOWING RECOGNITION CONTROL MODULE
VIO/BLK WIRE
VIO/RED WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (3 of 7) -> ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
