Audi A5 I (2007-2011) driver's side rear safety belt tensioner igniter Wiring diagram
This page shows the only wiring diagram for the component.driver's side rear safety belt tensioner igniter, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side rear safety belt tensioner igniter (1 of 1)
AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE)
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DRIVER'S HEAD CURTAIN AIR BAG IGNITER
DRIVER'S KNEE AIR BAG IGNITER (UNDER LEFT SIDE OF DASH)
DRIVER'S SAFETY BELT SWITCH
DRIVER'S SIDE REAR SAFETY BELT TENSIONER IGNITER
FRONT PASSENGER'S AIR BAG IGNITER (BEHIND RIGHT SIDE OF DASH)
FRONT PASSENGER'S HEAD CURTAIN AIR BAG IGNITER
FRONT PASSENGER'S KNEE AIR BAG IGNITER (UNDER RIGHT SIDE OF DASH)
FRONT PASSENGER'S SIDE REAR SAFETY BELT TENSIONER IGNITER
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
IGNITER
NCA WIRE
RED WIRE
SOLID STATE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> DRIVER'S SIDE REAR SAFETY BELT TENSIONER IGNITER
