Audi A5 I (2007-2011) driver's side can separating plug Wiring diagram
This page shows the only wiring diagram for the component.driver's side can separating plug, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side can separating plug (1 of 1)
A/C PRESSURE/ TEMPERATURE SENSOR
ANTI-THEFT ALARM SYSTEM SENSOR
CD CHANGER
CHARISMA SWITCH MODULE
CONTROL MODULE (CENTER OF DASH)
DIGITAL RADIO
DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMP)
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S
DRIVER'S SIDE CAN SEPARATING PLUG
FRONT DOOR)
FRONT INFORMATION DISPLAY CONTROL HEAD
GARAGE DOOR OPENER CONTROL HEAD
GRN/VIO WIRE
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT)
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PREMIUM BASE
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
TV TUNER (LEFT REAR OF LUGGAGE COMPT)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL)
VIO WIRE
VIO/YEL WIRE
W/ MMI BASIC
W/ MMI HIGH
Go to component -> Computer data lines circuit (2 of 3) -> DRIVER'S SIDE CAN SEPARATING PLUG
