Audi A5 I (2007-2011) driver's seat adjustment control head Wiring diagram
This page shows the only wiring diagram for the component.driver's seat adjustment control head, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat adjustment control head (1 of 1)
BACKREST
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST ADJUSTMENT MOTOR (IN LEFT FRONT SEAT BACK)
DRIVER'S HEAD RESTRAINT HEIGHT ADJUSTMENT MOTOR/SENSOR
DRIVER'S SEAT ADJUSTMENT CONTROL HEAD
DRIVER'S SEAT CIRCUIT BREAKER (BEHIND LEFT KICK PANEL)
DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR/SENSOR
DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR/SENSOR
FORE/AFT
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HEAD RESTRAINT
HEIGHT
HOT AT ALL TIMES
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
TILT
WHT/GRN WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> DRIVER'S SEAT ADJUSTMENT CONTROL HEAD
