Audi A5 I (2007-2011) (below right headlight assembly) wiring diagram
This page shows the only wiring diagram for the component.(below right headlight assembly), which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(below right headlight assembly) wiring diagram (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/YEL WIRE
FUEL METERING VALVE (RIGHT FRONT OF ENGINE)
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INTAKE MANIFOLD TUNING (IMT) VALVE (FRONT OF ENGINE)
LEAK DETECTION PUMP (LDP)
OIL PRESSURE REGULATOR VALVE (LEFT SIDE OF ENGINE)
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
SECOND- ARY AIR INJECTION (AIR) PUMP FUSE
SECONDARY AIR INJECTION (AIR) PUMP MOTOR
SECONDARY AIR INJECTION (AIR) PUMP RELAY
SECONDARY AIR INJECTION (AIR) SOLENOID VALVE
SECONDARY AIR INJECTION (AIR) SOLENOID VALVE 2
VIO WIRE
VIO/GRN WIRE
VIO/RED WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.2l (7 of 8) -> (BELOW RIGHT HEADLIGHT ASSEMBLY)
