Audi A5 I (2007-2011) backup 2 right taillamp assembly 2 Wiring diagram
This page shows the only wiring diagram for the component.backup 2 right taillamp assembly 2, which is found in the car Audi A5 I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup 2 right taillamp assembly 2 (1 of 1)
AUTOMATIC DAY/ NIGHT INTERIOR MIRROR
BACKUP
BACKUP 2
BACKUP 2 RIGHT TAILLAMP ASSEMBLY 2
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DIRECT SHIFT GEARBOX (DSG) MECHATRONIC (AT TRANSMISSION)
GRN/VIO WIRE
GRN/WHT WIRE
GRY/WHT WIRE
LEFT TAILLAMP ASSEMBLY 1
LEFT TAILLAMP ASSEMBLY 2
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PRNDS
RED WIRE
RIGHT TAILLAMP ASSEMBLY 1
SELECTOR LEVEL SENSOR SYSTEM CONTROL MODULE
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN)
TRUNK LID ALARM SWITCH
W/ DIRECT SHIFT
W/O DIRECT SHIFT COMPUTER DATA LINES SYSTEM
YEL WIRE
YEL/RED WIRE
Go to component -> Backup lamps circuit -> BACKUP 2 RIGHT TAILLAMP ASSEMBLY 2
