Audi A5 I (2007-2011) access/start authorization button (w/ start/stop button) Wiring diagrams
This page contains all the electrical diagrams for the component. access/start authorization button (w/ start/stop button), in which he is found in the car Audi A5 I (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
access/start authorization button (w/ start/stop button) wiring diagram (1 of 2)
ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
BLK/BRN WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
FUSE CARRIER 1 FUSE 10
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
PRNDS
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN)
TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL)
Go to component -> A/t circuit, 6 speed a/t -> ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
access/start authorization button (w/ start/stop button) wiring diagram (2 of 2)
4.2L 3.2L
ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 2
BLK/BRN WIRE
BLK/VIO WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DIRECT SHIFT GEARBOX (DSG) MECHATRONIC (AT TRANSMISSION)
ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER)
FUSE 1
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED FUSE CARRIER 1 FUSE 10
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
PRNDS
RELAY/FUSE CARRIER E BOX SB (IN LEFT PLENUM CHAMBER E-BOX)
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
TEMPERATURE SENSOR (IN CONTROL MODULE)
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL)
Go to component -> A/t circuit, with direct shift (1 of 2) -> ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
