Car Wiring Diagrams for Steering column electronic systems control module circuit for Audi A4 B9 facelift (2019-2024)

2.0L TURBO DBPA 3.0L TURBO BLK WIRE BLU WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH DRIVER AIR BAG IGNITER (IN STEERING WHEEL) DRIVER AIR BAG RELEASE VALVE IGNITER ENGINE/ MOTOR CONTROL MODULE FUSE 12 FUSE 16 FUSE PANEL C GRN WIRE HEATED STEERING WHEEL HORN SIGNAL ACTIVATION HOT AT ALL TIMES NCA WIRE PNK WIRE RED WIRE RED/GRN WIRE RED/VIO WIRE SPIRAL SPRING STEERING ANGLE SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING COLUMN) TURN SIGNAL SWITCH VIO WIRE VIO/YEL WIRE W/ CRUISE CONTROL W/ HEATED STEERING WHEEL WHT WIRE WINDSHIELD WIPER INTERMITTENT MODE SWITCH WINDSHIELD WIPER SWITCH YEL WIRE

4-PIN CONNECTOR AIR BAG CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE HEATED STEERING WHEEL SENSOR LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE RED WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL STEERING WHEEL HEATING BUTTON TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON VIO WIRE WHT WIRE YEL WIRE
