Audi A4 B9 facelift (2019-2024) memory seat/steering column adjustment control module Wiring diagram
This page shows the only wiring diagram for the component.memory seat/steering column adjustment control module, which is found in the car Audi A4 B9 facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory seat/steering column adjustment control module (1 of 1)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
COUPLING POINT IN LEFT REAR SEAT
COUPLING POINT IN THE LEFT REAR DOOR
COUPLING STATION IN LEFT FRONT SEAT
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DRIVER MULTI- CONTOUR COLUMN SEAT CONTROL MODULE
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT SWITCH MODULE
DRIVER SIDE MASSAGE FUNCTION BUTTON
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR DOOR LOCK UNIT
DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER VOLUME CONTROL
EARLY PRODUCTION
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRONT A/C DISPLAY CONTROL HEAD
FRONT INFORMATION DISPLAY CONTROL HEAD
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT CLUSTER OPERATION BUTTON
LATE PRODUCTION
LEFT FRONT FOOTWELL LAMP
LEFT FRONT SEAT BELT
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT EXTENSION HEATING ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT
LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT INSTRUMENT PANEL VENT ILLUMINATION BULB
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT, LEFT REAR HEATED SEAT TEMPERATURE SENSOR
LEFT REAR DOOR AMBIENT LIGHTING BULB 1
LEFT REAR DOOR CONTOUR ILLUMINATION LAMP
LEFT REAR DOOR COUPLING POINT
LEFT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
LEFT REAR FOOTWELL LAMP
LEFT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
LEFT REAR SEAT COUPLING STATION
LIGHT SWITCH
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
MOBILE DEVICE CHARGER 1
NCA WIRE
NEAR FIELD COMMUNICATION CONTROL MODULE 2
REAR A/C DISPLAY CONTROL HEAD
REAR VIEW CAMERA SYSTEM CONTROL MODULE SHIELD
RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
STEERING COLUMN ELECTRONICS CONTROL MODULE
USB CHARGING SOCKET 2
USB DISTRIBUTOR
W/ AUXILIARY LAMPS
W/ FPK ACTIVE INFO DISPLAY
W/ SEAT DEPTH ADJUSTMENT
W/O FPK ACTIVE INFO DISPLAY
WAGON
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component -> Ground distribution circuit (3 of 7) -> MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
