Audi A4 B9 (2015-2020) Charging circuit

BATTERY BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT FUSE PANEL A GENERATOR, VOLTAGE REGULATOR INSTRUMENT CLUSTER MAIN FUSE CARRIER ORG/BRN WIRE RIGHT COUPLING POINT IN ENGINE COMPARTMENT STARTER SUPPLEMENTAL RESTRAINTS SYSTEM VIO WIRE VIO/WHT WIRE
