Car Wiring Diagrams for Heated seats circuit, w/ ventilation for Audi A4 B9 (2015-2020)

BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DRIVER SEAT BACKREST COUPLING POINT FUSE 1 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B GRN WIRE GRN/BRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT SEAT BACKREST FAN 1 LEFT FRONT SEAT COUPLING STATION LEFT FRONT SEAT CUSHION FAN 1 LEFT FRONT SEAT HEATED BACKREST LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY & FUSE CARRIER 1 VIO/WHT WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE SEAT VENTILATION SWITCH FRONT A/C DISPLAY CONTROL HEAD FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SIDE SEAT VENTILATION SWITCH 2 GRN WIRE GRN/BRN WIRE LEFT SEAT HEATING BUTTON ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT SEAT BACKREST FAN 1 RIGHT FRONT SEAT COUPLING STATION RIGHT FRONT SEAT CUSHION FAN 1 RIGHT FRONT SEAT HEATED BACKREST RIGHT FRONT SEAT HEATING ELEMENT, RIGHT FRONT SEAT TEMPERATURE SENSOR RIGHT SEAT HEATING BUTTON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE
