Audi A4 B9 (2015-2020) w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa Wiring diagrams

This page contains all the electrical diagrams for the component. w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa, in which he is found in the car Audi A4 B9 (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa (1 of 3)

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa for Audi A4 B9 (2015-2020) (1 of 3)

Get access

BLK/GRN WIRE BLK/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM COOLANT RECIRCULATION PUMP COOLANT SHUT-OFF VALVE ENGINE CONTROL MODULE ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET FUSE 13 FUSE 14 FUSE 2 FUSE 3 FUSE 8 FUSE PANEL 1 FUSE PANEL A FUSE PANEL B GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT COUPLING POINT IN ENGINE COMPARTMENT N/A PNK/WHT WIRE RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RELAY & FUSE CARRIER 1 SUPPRESSOR VIO/WHT WIRE W/ HOT CLIMATES W/ TRAILER HITCH W/O TRAILER HITCH W/ LOW FAN OUTPUT 2.0L CYMC 2.0L DBPA WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Automatic a/c circuit, w/ climatronic (3 of 3) -> W/ TRAILER HITCH W/O TRAILER HITCH W/ LOW FAN OUTPUT 2.0L CYMC 2.0L DBPA

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa (2 of 3)

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa for Audi A4 B9 (2015-2020) (2 of 3)

Get access

Go to component -> Automatic a/c circuit, w/o climatronic (4 of 4) -> W/ TRAILER HITCH W/O TRAILER HITCH W/ LOW FAN OUTPUT 2.0L CYMC 2.0L DBPA

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa (3 of 3)

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa for Audi A4 B9 (2015-2020) (3 of 3)

Get access

BLK/GRN WIRE BLK/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM COOLANT RECIRCULATION PUMP COOLANT SHUT-OFF VALVE ENGINE CONTROL MODULE ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET FUSE 13 FUSE 14 FUSE 2 FUSE 3 FUSE 8 FUSE PANEL 1 FUSE PANEL A FUSE PANEL B GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES LEFT COUPLING POINT IN ENGINE COMPARTMENT N/A ORG/BRN WIRE OUTSIDE AIR TEMPERATURE SENSOR PNK/WHT WIRE RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RELAY & FUSE CARRIER 1 SUPPRESSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE W/ HOT CLIMATES W/ TRAILER HITCH W/O TRAILER HITCH W/ LOW FAN OUTPUT 2.0L CYMC 2.0L DBPA WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Cooling fan circuit -> W/ TRAILER HITCH W/O TRAILER HITCH W/ LOW FAN OUTPUT 2.0L CYMC 2.0L DBPA

Audi A4 B9 (2015-2020) w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa Wiring diagrams

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa (1 of 3)

List of components:

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa (2 of 3)

List of components:

Wiring diagram w/ trailer hitch w/o trailer hitch w/ low fan output 2.0l cymc 2.0l dbpa (3 of 3)

List of components:
