Audi A4 B9 (2015-2020) left parking brake motor Wiring diagram
This page shows the only wiring diagram for the component.left parking brake motor, which is found in the car Audi A4 B9 (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left parking brake motor (1 of 1)
ABS CONTROL MODULE ABS HYDRAULIC UNIT
ABS CONTROL MODULE FUSE 1
ABS CONTROL MODULE FUSE 2
ABS HYDRAULIC PUMP
ABS HYDRAULIC UNIT
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CLUTCH POSITION SENSOR
COMPUTER DATA LINES SYSTEM
DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1
DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2
DRIVING DYNAMICS REGULATION SWITCH VALVE 1
DRIVING DYNAMICS REGULATION SWITCH VALVE 2
FUSE 11
FUSE PANEL 2
FUSE PANEL B
GRN WIRE
GRN/VIO WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT ABS INLET VALVE
LEFT FRONT ABS OUTLET VALVE
LEFT FRONT ABS WHEEL SPEED SENSOR
LEFT PARKING BRAKE MOTOR
LEFT REAR ABS INLET VALVE
LEFT REAR ABS OUTLET VALVE
LEFT REAR ABS WHEEL SPEED SENSOR
M/T
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 1
RIGHT FRONT ABS INLET VALVE
RIGHT FRONT ABS OUTLET VALVE
RIGHT FRONT ABS WHEEL SPEED SENSOR
RIGHT PARKING BRAKE MOTOR
RIGHT REAR ABS INLET VALVE
RIGHT REAR ABS OUTLET VALVE
RIGHT REAR ABS WHEEL SPEED SENSOR
SUPPLEMENTAL RESTRAINTS SYSTEM
VACUUM SENSOR
WHEEL HUB ASSEMBLY)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Anti-lock brakes circuit (1 of 3) -> LEFT PARKING BRAKE MOTOR
