Audi A4 B9 (2015-2020) if equipped components w/ wireless data transfer Wiring diagram
This page shows the only wiring diagram for the component.if equipped components w/ wireless data transfer, which is found in the car Audi A4 B9 (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram if equipped components w/ wireless data transfer (1 of 1)
AIRBAG CONTROL MODULE
BATTERY
BATTERY INTERRUPT IGNITER
BATTERY JUMP START TERMINAL
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
EXTERNAL AUDIO SOURCE CONNECTION
FROM BOTTOM COUPLING POINT ON LEFT A-PILLAR (DIAGRAM 4 OF 6)
FRONT A/C DISPLAY CONTROL HEAD
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL A
FUSE PANEL H
GENERATOR, VOLTAGE REGULATOR
GRY/RED WIRE
IF EQUIPPED COMPONENTS W/ WIRELESS DATA TRANSFER
INFORMATION ELECTRONICS CONTROL MODULE 1
INSTRUMENT CLUSTER CONTROL MODULE
LIGHT SWITCH
MAIN FUSE CARRIER
MULTIMEDIA SYSTEM CONTROL HEAD
N/A
POWER STEERING CONTROL MODULE
RADIATOR FAN
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT COUPLING POINT IN ENGINE COMPARTMENT
STARTER
STEERING COLUMN ELECTRONICS CONTROL MODULE
SUPPRESSOR
TELEPHONE BASEPLATE
TERMINAL 30 WIRE JUNCTION 3
TO RELAY & FUSE CARRIER 1 (DIAGRAM 2 OF 6)
TO RELAY & FUSE CARRIER 2 (DIAGRAM 4 OF 6)
TO RELAY & FUSE CARRIER 2 (DIAGRAM 5 OF 6)
TO RELAY & FUSE CARRIER 2 (DIAGRAM 6 OF 6)
VIO/WHT WIRE
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component -> Power distribution circuit (1 of 6) -> IF EQUIPPED COMPONENTS W/ WIRELESS DATA TRANSFER
