Audi A4 B9 (2015-2020) driver side sill panel strip ambient lighting lamp Wiring diagram
This page shows the only wiring diagram for the component.driver side sill panel strip ambient lighting lamp, which is found in the car Audi A4 B9 (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side sill panel strip ambient lighting lamp (1 of 1)
BLU/GRY WIRE
BLU/VIO WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (CENTER OF DOOR)
DRIVER EXIT WARNING LAMP
DRIVER SIDE DOOR AMBIENT LIGHTING LAMP
DRIVER SIDE DOOR SPEAKER TRIM LAMP
DRIVER SIDE ENTRY LAMP
DRIVER SIDE REAR ENTRY LAMP
DRIVER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
FUSE 15
FUSE PANEL 2
FUSE PANEL B
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
LEFT FRONT DOOR AMBIENT LIGHTING BULB 1
LEFT FRONT DOOR CONTOUR ILLUMINATION LAMP
LEFT FRONT FOOTWELL LAMP
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 1
RIGHT FRONT FOOTWELL LAMP
VIO/RED WIRE
VIO/YEL WIRE
W/ AUXILIARY LAMPS
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (2 of 5) -> DRIVER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
