Audi A4 B9 (2015-2020) current coding resistance 1 for left headlamp Wiring diagram
This page shows the only wiring diagram for the component.current coding resistance 1 for left headlamp, which is found in the car Audi A4 B9 (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram current coding resistance 1 for left headlamp (1 of 1)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE
BLK/BLU WIRE
BLK/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON ROOF
CURRENT CODING RESISTANCE 1 FOR LEFT HEADLAMP
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 11
FUSE 12
FUSE 3
FUSE 9
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL B
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/RED WIRE
HEADLAMP SWITCH ILLUMINATION BULB
HOT AT ALL TIMES
HUMIDITY SENSOR
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT FOG LAMP BULB
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HID HEADLAMP BULB
LEFT LIGHT CONTROL MODULE
LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR
LIGHT SWITCH
ORG/BRN WIRE
PARKING BRAKE INDICATOR LAMP
POSITION LAMP INDICATOR LAMP
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY & FUSE CARRIER 1
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD PROJECTION HEAD-UP DISPLAY BUTTON
YEL WIRE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Headlights circuit, w/ hid (1 of 2) -> CURRENT CODING RESISTANCE 1 FOR LEFT HEADLAMP
