A/t circuit, 8 speed a/t for Audi A4 B8 facelift (2011-2015)

AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7 BLK/GRN WIRE BLU/BLK WIRE BLU/GRY WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVE POSITION SENSOR FUSE 12 FUSE CARRIER 1 FUSE 1 FUSE CARRIER 1 FUSE 10 FUSE PANEL C (BEHIND LEFT END OF DASH) GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED ORG/BLK WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RED/BRN WIRE RELAY/ FUSE PANEL B (IN PLENUM CHAMBER ELECTRONICS BOX) SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ON SHIFTER UNIT) SOLENOID VALVE 1 TRANSMISSION CONTROL MODULE (TCM) (IN MECHATRONIC UNIT) TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)

AIR BAG SPIRAL SPRING/RETURN SPRING (W/ SLIP RING) (IN STEERING COLUMN) BEHIND STEERING WHEEL) BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 5 FUSE CARRIER 1 FUSE CARRIER 2 FUSE 12 FUSE PANEL D (BEHIND RIGHT END OF DASH) HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MODE MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE RED/WHT WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL STEERING COLUMN ELECTRONICS CONTROL MODULE (ON STEERING COLUMN, STEERING WHEEL CONTROL UNIT STEERING WHEEL VIBRATION MOTOR (W/ LANE ASSIST) TIPTRONIC DOWNSHIFT BUTTON ON STEERING WHEEL (W/ TIPTRONIC) TIPTRONIC UPSHIFT BUTTON ON STEERING WHEEL (W/ TIPTRONIC) W/ TIPTRONIC W/ LANE ASSIST
